Premium Eaton / Cutler-Hammer BRH245 – 45A 2 Pole Miniature Circuit Breaker

Designed to handle demanding 240V loads, the Eaton BRH245 is a 45A, two-pole miniature circuit breaker. It utilizes proven thermal-magnetic trip technology to protect residential and commercial systems. The breaker installs into Eaton Type BR load centers and compatible enclosures. Its box lug terminals are rated to accept #14-4 AWG copper or aluminum conductors. With a 120/240 VAC rating, this unit delivers a 22kAIC interrupting capacity. It is HACR rated and features a common trip mechanism.
